S215T - 200 Series

Sliding timber

next previous
  Thermal Performance
U Value (typical) 1
  Sound Performance
Decibels (typical) 34db
  Security Performance
PAS 24

Opening types Lift and Slide
Frame depth 184 mm
Whole window U-value 1 W/m²K
Glass U-value 0.64 W/m²K
Glass package 40 mm triple glazed, two panes Low-E, argon filled
Sound insulation 34 db
Air permeability Class 4 (EN 12207:2000)
Watertightness Class E750 (EN 12208:2001)
Wind load Class C4 (EN 12210:2001)
Timber Colours RAL
Aluminium Colours RAL, IGP textured
Data sheet S215T.pdf
Drawing S215T.dwg
  Thermal Performance
U Value (typical) 1
0.6 0.8 1.0 1.2 1.4 1.6 1.8

  Sound Performance
Decibels (typical) 34db
  Security Performance
PAS 24
