p11t - 100 Series

Outward Opening Timber

116mm (optionally 89mm) laminated timber outward opening window with double glazing.
next previous

If you are looking for a traditional timber casement or cottage window design, Norrsken’s P11T Outward Opening Timber Window is perfect. The all timber construction of the windows makes it suitable where conservation or planning requirements stipulate timber.

This double glazed outward opening window delivers very good performance - above average for a double glazed window.

The application of technically advanced sprayed coatings (in a full range of RAL colours) gives enhanced durability and a superb finish.

The double glazed unit is a 24 mm unit with argon gas filling, warm edge spacer bar and an internal pane of Low-E glass. Whole window U-Values are around 1.2 W/m²K.

The frame is available in two depths 116 mm (+ 12.5 mm for aluminium cladding) and 92 mm. On the deeper section frame a decorative moulding finish is available.

  Thermal Performance
U Value (typical) 1.24
  Sound Performance
Decibels (typical) 33db
  Security Performance
PAS 24

Opening types Fixed pane, Top hung, Side hung, Fully reversible
Frame depth 89/116 mm
Whole window U-value 1.24 W/m²K
Glass U-value 1.12 W/m²K
Glass package 24 mm double glazed, one pane LowE, argon filled
Sound insulation 33 db
Air permeability Class 4 (EN 12207:2000)
Watertightness Class E1200 (EN 12208:2001)
Wind load Class 5C (EN 12210:2001)
Timber Colours RAL
Aluminium Colours RAL, IGP textured
Data sheet p11t.pdf
Drawing p11t.dwg
  Thermal Performance
U Value (typical) 1.24
0.6 0.8 1.0 1.2 1.4 1.6 1.8

  Sound Performance
Decibels (typical) 33db
  Security Performance
PAS 24
